Oscilloscope Probe 1:100 - HP-9258 订购编号:
点击这里发送询价请详细填写一下内容，包括产品原产国、品牌完整名称以及您所能得到的所有信息，这将有助于我们准确迅速的报价。非常感谢！
Oscilloscope Probe 1:100 - HP-9258 250 MHz bandwidth, rated 1.2 kV.
The Oscilloscope Probe 1:100 - HP-9258 is a low-input capacitance high voltage 1:100 oscilloscope probe with a bandwidth of 250 MHz designed and calibrated for use on scopes having an input impedance of 1 MOhm shunted by 20 pF. However, it may be compensated for use with oscilloscopes having an input capacitance of 10 - 35 pF.
The modular construction facilitates simple field replacement of the major parts.
Oscilloscope Probe 1:100 - HP-9258 key specifications
| Oscilloscope Probe 1:100 - HP-9258 |
|---|
| 1:100 attenuation |
| 1.4 ns rise time |
| 250 MHz bandwidth |
| 1200 V CAT II rating |
Models
The following models of the Oscilloscope Probe 1:100 - HP-9258 are available:
| Order code | |
|---|---|
| HP-9258 |
Package contents
The Oscilloscope Probe 1:100 - HP-9258 is delivered with:
| Amount | Item |
|---|---|
| 1 | Oscilloscope Probe 1:100 - HP-9258 |
| 1 | Sprung hook |
| 1 | Ground lead |
| 1 | Insulating tip |
| 1 | IC tip |
| 1 | Measuring tip |
| 1 | BNC adapter |
| 1 | Sprung earth tip |
| Various | Color coding rings |
Oscilloscope Probe 1:100 - HP-9258 specifications
The table below shows detailed specifications of the Oscilloscope Probe 1:100 - HP-9258.
| Oscilloscope Probe 1:100 - HP-9258 - Specification | |
|---|---|
| Attenuation ratio | 100:1 |
| Max. input voltage | 1500 Vrms CAT II (2000 V DC + peak AC), derating with frequency, see below |
| Input resistance | 100 MOhm (when used with oscilloscopes which have 1 MOhm input) |
| Input capacitance | Approx. 5.5 pF |
| Bandwidth | DC to 250 MHz |
| Rise time | 1.4 ns |
| Compensating range | 10 to 35 pF |
| Cable length | 1.3 m (51 inch) |
| Operating temperature | -10 °C to 55 °C |
| Relative humidity | ≤ 85 % (at 35 °C) |
| Safety | meets EN61010-031 CAT II |
| Accessories |
Channel identifier clip Sprung hook Ground lead Insulating tip IC tip Adjusting tool Measuring tip BNC adapter |
Voltage derating curve
