便携式压力指示器和远程传感器EJH-68453-44 订购编号:EJH-68453-44
点击这里发送询价请详细填写一下内容，包括产品原产国、品牌完整名称以及您所能得到的所有信息，这将有助于我们准确迅速的报价。非常感谢！
GE Druck Portable Pressure Indicator with Remote Sensor, 0 to 100 psia; 1/8" NPT(F)
-
- Audiovisual alarm alerts you once high setpoint is reached--perfect for maintenance and trouble shooting.
- NEMA 12(IP54) case--ideal for field use.
- View minimum and maximum readings as well as ambient temperature.
- Recalibrate using zero and TARE keys.
- Automatic shut-off and low-battery indication.
- Perform a one-minute LEAK test with count-down timer displayed.
What's Included:
Gauges include three AA batteries.
| Specifications | ||
| Product Type | Digital Pressure Indicators | |
| Media compatibility | clean, inert, non-corrosive gases or liquids | |
| Unit of Measurement | psi, " H2O, ft H2O, m H2O, " Hg, mm Hg, mHg, mbar, bar, Pa, hPa, kPa, MPa, Kg/cm2, and user-definable scale | |
| Resolution | 0.01 psi | |
| Range | 0 to 100 psia | |
| Max pressure (psi) | 100 | |
| Process connection | 1/8" NPT(F) | |
| Battery life | 300 hours, average | |
| Accuracy | ±0.1% full-scale | |
| Power | three AA batteries (included) | |
| Model | DPI 705R | |
| Qty/ea | 1 | |
| Manufacturer number | I705R-100PSIG | |
| Brand | GE Druck | |
| Display | 5-digit LCD, 0.5"H | |
| Make | DPI 705 | |
Calibrations
InnoCal, NIST Calibration Service for Pressure/Vacuum Gauges, = 0.75%
