Nicolet™ iS™ 50R Research Spectrometer
Thermo Scientific™ 相关应用: Spectroscopy Elemental Isotope Analysis
Equipped with dual sources and triple detector optics, multiple on-board digitizers and easy access to spectrometer data and control signals, the Thermo Scientific™ Nicolet™ iS™ 50R Spectrometer includes all the flexibility and performance of the Thermo Scientific™ Nicolet™ iS™ 50 Spectrometer with the added capabilities for the research spectroscopist.
The Nicolet iS 50R Spectrometer incorporates the latest electronic and digital technology for advanced continuous scan, step-scan and dual channel applications. Using the Vectra series interferometer, the Nicolet iS50R offers the best mirror position accuracy in the industry. Precise positioning of the moving mirror is critical to the ultimate signal-to-noise ratio of the experiments. Unlike traditional air bearing and mechanical interferometers, the Vectra series interferometer is nearly immune to normal laboratory vibrations and acoustic noises making an ideal choice for the most sensitive and highly demanding step-scan experiments. All configurations of the Nicolet iS 50R Spectrometer support amplitude modulation and time-resolved step-scan spectroscopy. When you include the optional Vectra-Piezo interferometer, you add advanced phase and multiple modulation capabilities to your Nicolet iS 50R.
840-235300 |
- |
The Thermo Scientific Nicolet iS 50R carries forward all the flexibility and performance of the Nicolet iS50 Spectrometer system, with the added capabilities for the research spectroscopist. |
Materials science, photochemistry and optical research |
申请报价 |
|
产品规格 |
- |
高度(英制) |
11 in. |
高度(公制) |
27.6 cm |
重量(英制) |
132 lb. |
重量(公制) |
60 kg |
适用 |
All Smart Accessories |
应用 |
Materials science, photochemistry and optical research |
宽度(英制) |
25 in. |
宽度(公制) |
62.6 cm |
接口 |
USB 2.0 |
射束分离器 |
Mid-, near- amd far-IR, as well as visible beamsplitters available |
兼容性 |
Smart Accessories; Nicolet iS 50 modules; Nicolet Continuum Microscope |
功能校验 |
ValPro and SPV |
组件 |
Sources, detectors and beamsplitters |
电源 |
100-240 V 50/60 Hz |
深度(英制) |
27 in. |
深度(公制) |
69.8 cm |
源类型 |
Dual Source capable: Polaris™ long-life IR source |
光谱范围 |
Standard System 7,800 – 350 cm-1; Multi-Range Optics |
描述 |
The Thermo Scientific Nicolet iS 50R carries forward all the flexibility and performance of the Nicolet iS50 Spectrometer system, with the added capabilities for the research spectroscopist. |
光谱分辨率 |
0.09 cm-1 resolution |
检测器类型 |
Three-position Paraflect detector mirror; Top-mounted DLaTGS Detector with KBr window |
|
返回顶部
描述
Key features of all iS50R Spectrometers include:
-
Step-Scan Control System and SST Electronics
-
Standard dual-channel digitizers
-
Auto-Tune
-
Rapid scanning for fast kinetics
-
0.09cm-1 resolution
-
Touch Point one-touch sampling operation
-
Four-position Quadraflex source mirror
-
Long Lifetime Polaris™ infrared source
-
Without iS 50 ABX: Internal storage for two additional beam splitters
-
Mounts for J-port emission optics and Raman InGaAs detect
-
Three-position Paraflect detector mirror
-
Top-mounted DLaTGS Detector with KBr window
-
Aligned mounting plates front/rear
-
High-speed USB 2.0 interface
-
Upgradeable to include iS50 ATR
-
Built-in, wide-range diamond ATR
-
Accepts all Smart Accessories and many others
-
Expandable with the iS 50 GC-IR and iS 50 NIR modules
-
Ready to accept iS50 Raman Module
-
Compatible with Continuum FT-IR Microscope and TGA Accessory
-
Ready for iS 50 ABX automatic beam splitter changer
-
Internal storage for two additional beam splitters
-
Internal Validation wheel for SPV or Thermo Scientific™ ValPro™ Qualifications
The Nicolet iS 50R Spectrometer is controlled by the proven Thermo Scientific™ OMNIC™ Research Software, providing a powerful Windows compatible interface for complete data collection and processing.
OMNIC 9 Research Software
All of the OMNIC Sortware standard features, plus advanced features to support research applications:
-
OMNIC Series for time-based data collection and analysis software for kinetics and hyphenated techniques
-
SST software suite of advanced research tools supporting:
-
FT-IR Step-scan amplitude, phase, multiple modulation
-
Step-scan time-resolved spectroscopy
-
Dual-channel polarization modulation
-
Phase array operations for dynamic FT-IR data manipulation
-
VCD intensity calibration
-
SpectraCorr™ Software for 2-D correlation Spectroscopy
-
MacrosPro for advanced workflow and application development
-
Extensive help system for SST features
